DL-6CJDCZ-780-5 electrostatic dust removal cleaner adopts five 780mm rollers. Powered by 1.5kw (380V 50Hz) with dual vibration motors, it delivers cleaning efficiency over 92% and hourly capacity ≥300kg. Optimized electrostatic separation design effectively clears lint, dust and lightweight foreign contaminants in tea. With mature conveyor and sorting bed structure, this machine balances processing yield and purification effect, a cost-effective option for medium-scale tea production lines.
| DESCRIPTION |
The electrostatic cleaner is a new patented product of our company.
The electrostatic tea ESP cleaner sorter adsorption generated by 4-10 electrostatic rollers extracts impurities in the tea, such as hair, broom bristles, tea fluff ash, thatch, woven bag silk, plastic scraps, iron filings, etc.
| ADVANTAGE |
The impurity removal rate is more than 90%, and the productivity is 300-400 kg per hour, which greatly improves the efficiency of the impurity removal process and greatly reduces the amount of labor.
The machine is equipped with screens of different specifications and can carry out screening operations at the same time, sieving out tea dregs and tea dust.
It has the advantages of uniform tea separation, high impurity removal rate, compact structure, reliability and durability, and easy maintenance. It is a powerful guarantee equipment for the clean quality of tea.
| APPLICATION |
Tea ESP Electrostatic Dust Removal Clearner Machine is suitable for processing black / green / oolong / white / dark / herbal tea, the following is the working time required for the above tea production.
| Type Of Tea | Working Time |
| Black Tea | / |
| Green Tea | / |
| White Tea | / |
| Oolong Tea | / |
| Herbal Tea | / |
The above data is for reference only, and the specific processing time shall be determined according to the actual situation.
| SPECIFICATION |
Tea ESP Electrostatic Dust Removal Clearner Machine specification list:
| Model | DL-6CJDCZ-780-5 |
| Size | 5540×1340×1700 mm |
| Power | 380V 50Hz |
| Roller Length | 1.5 kw |
| Roller Quantity | 5 pcs |
| Rate | ≥92% |
| Capacity | ≥ 300 kg/h |
Specification of all of Tea Electrostatic Cleaner.
| Model | DL-6CJDCZ-780-3 | DL-6CJDCZ-780-5 | DL-6CJDCZ-1350-8 |
| Overall Dimensions | 4300×1430×1700 mm | 5540×1340×1700 mm | 7470×2020×1730 mm |
| Sorting Bed Dimension | 2100×1430×1700 mm | 3380×1340×1700 mm | 5310×2020×1730 mm |
| Conveyor Dimension | 2100×1430×1700 mm | 2100×1430×1700 mm | 2160×2000×1730 mm |
| Voltage | 380V 50Hz | 380V 50Hz | 380V 50Hz |
| Power | 1.5 kw | 1.5 kw | 2 kw |
| Vibration Motor Quantity | 2 pcs | 2 pcs | 2 pcs |
| Roller Length | 780mm | 780mm | 1350mm |
| Roller Quantity | 3 pcs | 5 pcs | 5 pcs |
| Clean Efficiency | ≥ 90% | ≥ 92% | ≥ 96% |
| Capacity | ≥ 300 kg/h | ≥ 300 kg/h | ≥ 400 kg/h |
If you have special need, it can be customized according to the needs of customers.
